Model G1026 (Mfd. Since 10/13)

Stand & Table Parts List

REF PART # DESCRIPTION REF PART # DESCRIPTION

1 P1026001 STAND BODY 33-2 P1026033-2 OL RELAY SDE RA-30 18-26A

2 P1026002 EXTENSION WING 35V2 P1026035V2 FWD/REV SWITCH V2.04.10

3 P1026003 HEX BOLT 3/8-16 X 1 36 P1026036 SWITCH MOUNT BRACKET

4 P1026004 LOCK WASHER 3/8 37 P1026037 SWITCH BOX

5 P1026005 PHLP HD SCR 1/4-20 X 3/8 39 P1026039 SWITCH BOX COVER V1.10.95

6A P1026006A STAND SIDE COVER V2.01.06 40 P1026040 TAP SCREW #6 X 1/2

7 P1026007 HEX BOLT 3/8-16 X 3/4 41 P1026041 SPINDLE HEIGHT SCALE

8 P1026008 FLAT WASHER 3/8 42V2 P1026042V2 CORD GROMMET V2.04.10

9 P1026009 TABLE INSERT 1-1/2" ID 43V2 P1026043V2 MOTOR CORD 14G 4C 30" V2.04.10

10 P1026010 TABLE INSERT 2-15/16" ID 44AV2 P1026044AV2 SWITCH CORD 14AWG 3C 27" V2.04.10

11 P1026011 TABLE INSERT RING 4-1/4" ID 44V2 P1026044V2 POWER CORD 14G 3C 76" 6-15 V2.04.10

12 P1026012 STARTING PIN 45 P1026045 WHITE SWITCH COVER SCREW V1.12.95

13 P1026013 FLAT HD SCR 10-24 X 1 46V2 P1026046V2 ADJUSTABLE HANDLE 5/16-18 V2.02.06

14 P1026014 BARREL SCREW 7/16-14 X 1/2 55 P1026055 STRAIN RELIEF M16 TYPE-6 ST

15 P1026015 TABLE 56 P1026056 STRAIN RELIEF M16 TYPE-1 SNAP-IN

16 P1026016 FLAT HD SCR 5/16-18 X 1-1/4 57 P1026057 REAR STAND PANEL

17 P1026017 FENCE BOARD 58 P1026058 FLANGE SCREW 10-24 X 3/8

18A P1026018A FENCE MOUNT (RH) V2.12.95 59 P1026059 PHLP HD SCR 10-24 X 1/2

21 P1026021 FENDER WASHER 5/16 60 P1026060 PHLP HD SCR 10-24 X 3/8

22 P1026022 HEX NUT 5/16-18 61 P1026061 HEX NUT 10-24

23 P1026023 SET SCREW 5/16-18 X 3/8 64 P1026064 LOCK WASHER #10

24 P1026024 CAP SCREW 5/16-18 X 3/4 65 P1026065 FLAT WASHER #10

25 P1026025 HAND KNOB 3/8" 66 P1026066 EXT TOOTH WASHER #10

26 P1026026 SET SCREW 5/16-18 X 1/4 67 P1026067 SWITCH PADLOCK

27A P1026027A FENCE ADJ SCREW 1/2-13 X 4-1/4 V2.12.95 68 P1026068 PADLOCK STORAGE HOOK

28 P1026028 ADJUST SCREW BRACKET 69 P1026069 STRAIN RELIEF M16 TYPE-6 ST

29A P1026029A MAIN FENCE HOUSING V2.02.06 70 P1026070 MOTOR SHIPPING BRACE

30 P1026030 CAP SCREW 3/8-16 X 1 71 P1026071 HEX NUT 5/16-18

31A P1026031A FENCE MOUNT (LH) V2.12.95 72 P1026072 FLAT WASHER 5/16

32 P1026032 MAGNETIC SWITCH MOUNT BRACKET 73 P1026073 HEX BOLT 5/16-18 X 3/4

33 P1026033 MAGNETIC SWITCH 3HP 1PH 505 P1026505 COMPLETE FENCE ASSY

33-1 P1026033-1 CONTACTOR SDE MA-15 220V
