-56-

Model G1026 (Mfd. Since 10/13)

Motor & Handwheel Parts List

REF PART # DESCRIPTION REF PART # DESCRIPTION

101A P1026101A HANDWHEEL HANDLE V2.01.06 137 P1026137 SPINDLE BRACKET

102A P1026102A HANDWHEEL V2.01.06 140 P1026140 HEX BOLT 3/8-16 X 1-1/2

103 P1026103 SET SCREW 5/16-18 X 5/16 142 P1026142 FLAT WASHER 5/16

104 P1026104 SET SCREW 5/16-18 X 5/16 143 P1026143 LOCK WASHER 5/16

105 P1026105 LOCK COLLAR 145 P1026145 SET SCREW 5/16-24 X 5/8

107 P1026107 HEX BOLT 5/16-18 X 3/4 146 P1026146 V-BELT 7 X 690

108 P1026108 SHAFT MOUNT 147 P1026147 MOTOR PULLEY

109 P1026109 BUSHING 24 X 19 X 24 148 P1026148 HEX BOLT 5/16-18 X 1

111 P1026111 WORM SHAFT 149 P1026149 HEX BOLT 1/2-13 X 1-3/4

112 P1026112 GIB 150 P1026150 FLAT WASHER 1/2

113 P1026113 HEX NUT 5/16-18 151 P1026151 MOTOR MOUNT PLATE

114 P1026114 SET SCREW 5/16-18 X 1-3/8 152 P1026152 MOTOR 3HP 220V 1-PH

115A P1026115A ELEVATION HOUSING GREEN V2.10.98 152-1 P1026152-1 MOTOR FAN COVER

116 P1026116 HEX BOLT 1/2-13 X 1-3/4 152-2 P1026152-2 MOTOR FAN

117 P1026117 FLAT WASHER 1/2 152-3 P1026152-3 CAPACITOR COVER

118 P1026118 LOCK WASHER 1/2 152-4 P1026152-4 MOTOR JUNCTION BOX

120A P1026120A POINTER V2.02.98 152-5 P1026152-5 S CAPACITOR 400M 125V 1-3/4 X 3-3/8

123 P1026123 POINTER MOUNT 153 P1026153 KEY 5 X 5 X 30

126 P1026126 HEX BOLT 1/4-20 X 1/2 154 P1026154 HEX BOLT 5/16-18 X 3/8

128 P1026128 LOCK KNOB BOLT 155 P1026155 LOCK WASHER 1/2

130 P1026130 LOCK NUT 5/8-11 156 P1026156 FLAT WASHER 1/4

132 P1026132 BEARING FLAT WASHER 5/8 156-1 P1026156-1 HANDWHEEL WASHER

133 P1026133 ELEVATION BEVEL GEAR 157 P1026157 HEX NUT 5/16-18

133A P1026133A THRUST BEARING 51103 158 P1026158 HEX BOLT 5/16-18 X 3/4

135 P1026135 KEY 5 X 5 X 18 159 P1026159 TOP MOTOR SHIPPING BRACE

136 P1026136 ELEVATION LEADSCREW 3/4 X 7-1/2 160 P1026160 FLAT WASHER 5/16
