Grizzly G1026 User Manual

-58-
Model G1026 (Mfd. Since 10/13)
Spindle Parts List
Bore Diameter Height Replacement Part #
1/2'' 1''
1/4'' W1159
1/2'' 1''
3/8'' W1160
1/2'' 1''
1/2'' W1161
1/2'' 1''
3/4'' W1162
3/4'' 1-1/4''
1/4'' W1164
3/4'' 1-1/4''
3/8'' W1165
3/4'' 1-1/4''
1/2'' W1166
3/4'' 1-1/4''
3/4'' W1167
1'' 1-1/2''
1/4'' W1168
1'' 1-1/2''
3/8'' W1170
1'' 1-1/2''
1/2'' W1171
1'' 1-1/2''
3/4'' W1172
1'' 1-1/2''
1'' W1173
1-1/4'' 1-3/4''
1/4'' W1174
1-1/4'' 1-3/4''
3/8'' W1175
1-1/4'' 1-3/4''
1/2'' W1176
1-1/4'' 1-3/4''
3/4'' W1177
1-1/4'' 1-3/4''
1'' W1178
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P1026201 PHLP HD SCR 10-24 X 1/2 216 P1026216 SPINDLE 1"
202 P1026202 EXT RETAINING RING 35MM 217 P1026217 DRAWBAR 3/8-24 X 7-3/4
203 P1026203 QUILL FLANGE 218 P1026218 DRAWBAR NUT 3/8-24
204 P1026204 SPINDLE CARTRIDGE 219 P1026219 SPINDLE NUT 1/2" 2PC SET
205 P1026205 KEY 5 X 5 X 15 220 P1026220 SPINDLE NUT 3/4" 2PC SET
206 P1026206 BALL BEARING 6205ZZ 221 P1026221 SPINDLE NUT 1"-8 2PC SET
207 P1026207 INT RETAINING RING 25MM 222 P1026222 PIN
208 P1026208 INT RETAINING RING 52MM 223 P1026223 SPINDLE WASHER 1/2 X 26 X 3
209 P1026209 SPINDLE HOUSING 224 P1026224 SPINDLE WASHER 3/4 X 32 X 3
210 P1026210 EXT RETAINING RING 70MM 225 P1026225 SPINDLE WASHER 1 X 38 X 3
211 P1026211 SPINDLE PULLEY 226 P1026226 SPINDLE WRENCH SET
212 P1026212 TOOTHED WASHER 3/4" LARGE 226A P1026226A SPINDLE WRENCH HEXAGONAL
213 P1026213 SPANNER NUT 3/4-10 226B P1026226B SPINDLE WRENCH RECTANGULAR
214 P1026214 SPINDLE 1/2" 246 P1026246 COMBO WRENCH 7/8" X 1-1/4"
215 P1026215 SPINDLE 3/4"
Spacers
