** For packed pumps only (packed pumps standard with
distribution ring, recirculation lines, and hardened stainless
steel sleeves).
Materials of construction 1 4 00 0 1
General configuration (Horizontal)
Code no. Item
00 Standard
01 Double wear rings
02 Oil lube bearings
03 (01) + (02)
04 (01) + (05)
05 Recirculation lines
20 Double ext shaft
21 Double wear rings
22 Recirculation lines
24 (21) + (22)
30 Double ext shaft
31 Double wear rings
32 Recirculation lines
34 (31) + (32)
70 250 lb flange
71 Double wear rings
72 (71) + (73)
73 Recirculation lines
90 250 lb flange
91 Double wear rings
General configuration (Vertical)
Code no. Item
50 Standard (Vesconite for KPVS)
51 Double wear rings
52 Sleeve bearing
53 (51) + (52)
80 250 lb flange for 300 psi CWP
81 Double wear rings
82 Sleeve bearing
83 (81) + (82)
92 250 lb flange for 400 psi CWP
93 Double wear rings
94 Sleeve bearing
95 (93) + (94)
Shaft/sleeve metallurgy
0 = Steel/bronze
1 = Steel/stainless steel
3 = Stainless steell/bronze**
6 = Stainless steel/stainless steel or stainless steel/no sleeves
(KPVS)
7 = SS/hardened stainless steel
A = 316 SS/Ni Al Bronze
X = Special
Pump metallurgy
0 = Standard fitted
1 = Bronze fitted
2 = Standard all bronze
5 = All iron
8 = Ductile iron/bronze fitted
E = Ductile iron/stainless steel fitted
X = Special
Motor code 1782
Enclosure
1 = ODP
2 = TEFC
3 = Explosion Proof
Voltage
Hp
1-phase 3-phase
115/230 V 200 V 230/460 V
1/3
1/2
3/4
1
1-1/2
21
29
35
41
47
23
31
37
43
49
24
32
38
44
50
2
3
5
7-1/2
10
53
59
65
71
76
55
61
67
73
77
56
62
68
74
78
15
20
25
30
40
--
--
--
--
--
81
84
01
02
03
82
85
87
88
89
50
60
75
100
125
--
--
--
--
--
04
05
06
07
--
90
91
92
93
94
150
200
250
300
--
--
--
--
--
--
--
--
95
96
97
98
RPM
1 = 3500
2 = 1750
3 = 1150
