Chapter 2: Installation
The following steps are required to set up the indicator.
• Inspect indicator to ensure it is in good condition.
• Use connection diagrams to wire up load cell, power and auxiliary cables as required.
• Use the template provided for hole locations.
• Connect power to indicator and press [ON/OFF] key to turn the Model 250 ON.
• Refer to the Setup Parameter section on page 29 for information on configuring and calibrating the
Model 250.
• To turn the Model 250 OFF press and hold [ON/OFF] key for three seconds (until display blanks).
G
G
E
E
N
N
E
E
R
R
A
A
L
L
W
W
A
A
R
R
N
N
I
I
N
N
G
G
S
S
• Do not subject the Model 250 indicator to shock, excessive vibration or extremes of temperature
(before or after installation).
• Inputs are protected against electrical interference, but excessive levels of electro-magnetic radiation
and RFI may affect the accuracy and stability.
• The indicator should be installed away from any sources of excessive electrical noise.
• The load cell cable is particularly sensitive to electrical noise and should be located well away from
any power or switching circuits.
• For full EMC or for RFI immunity, termination of cable shields and correct grounding of the indicator
is essential.
E
E
L
L
E
E
C
C
T
T
R
R
I
I
C
C
A
A
L
L
S
S
A
A
F
F
E
E
T
T
Y
Y
• For your protection all electrical hardware must be rated for environmental conditions of use.
• Make sure all AC powered equipment is installed near an easily accessible power socket outlet.
• To avoid the possibility of electric shock or damage to the Model 250, always switch OFF or isolate
the indicator from the power supply before maintenance is carried out.
C
C
L
L
E
E
A
A
N
N
I
I
N
N
G
G
To clean and maintain the Model 250, never use harsh abrasive cleaners or solvents. Wipe the
indicator with a soft cloth slightly dampened with warm soapy water. For the stainless steel
models, use a cleaner specifically for stainless steel.
P
P
A
A
N
N
E
E
L
L
M
M
O
O
U
U
N
N
T
T
T
T
E
E
M
M
P
P
L
L
A
A
T
T
E
E
Use the panel mount template (included with the Model 250 and Model 250SS) for drill hole
locations. The template indicates positions for the two 4mm mounting screws through the panel.
Also displayed on the template is the position of the rectangular hole that should be cut to allow
for the connection of cables. The drilling template supplied with the indicator allows for front or
rear machining of the panel.
