APS-1102A User Manual
APS-1102A
4-38
b) When operating with the shortcut keys
 Operation step
The control of sequence operations, can also be performed with the shortcut keys at the bottom of the
control panel.
The START, STOP, and HOLD keys under “SEQUENCE” correspond to items in the CONTROL
selection box. Shortcut keys cannot be used to control branching.
Sequence shortcut keys 5.2.6
Figure 4-12. Sequence Shortcut Keys
