External control operation modes: Enable, disable
Control input:
Input level: High level: +4.0 V or higher
Low level: +1.0 V or lower
Non-destructive max. input: +10 V/5 V
Input impedance: Pull-up to +5 V at 47 k
Control items: Output on/off, sequence
start/stop, hold, branch
Status output:
Output level: 0 V/+5 V (open)
Output impedance: 100
Status items: Power on/off, output on/off, limiter
operation, software busy, sequence
operation step sync output
Terminal: D-sub 25-pin multi-connector
