GW Instek APS-1102A - Reset the Peak Current Hold Value

APS-1102A User Manual
APS-1102A
4-18
4. Press the TOP MENU key or the CANCEL key to return to the SET menu screen.
 The measured value window shows the peak value set in the measurement display.
Peak value
Peak hold value
4.2.4 Reset the peak current hold value
The APS-1102A includes a function that resets the peak current hold value.
A reset sets the peak current hold value to 0 Apk, and the maximum peak value of current is updated
until the next reset is performed.
The current peak value is reset automatically at power-on.
To reset the peak current hold value, select “MEASURE” in the MISC menu .
 Operation steps
1. Press the or key to move the cursor to the icon, then press the
ENTER
key.
ENTERCANCEL
Cursor
 The MISC menu is displayed.
