3.4 Main Operation Example
Main operations are described below in the following order.
 Power-on 3.4.1 Power on/off

 Set output mode 3.4.2 Setting output mode

 Set output voltage range 3.4.3 Setting output voltage range

 Set waveform 3.4.4 Setting waveform

 Set output voltage 3.4.5 Setting output voltage

 Set output frequency 3.4.6 Setting output frequency

 Use current limiter and setting range limiter 3.4.7 Using limiter functions

 Output on 3.4.8 Output on/off

 Check measured value 3.4.9 Using measurement functions

 Output off 3.4.8 Output on/off

 Power-off 3.4.1 Power on/off
