SAVE/RECALL
89
Waveform
Memory Depth
The memory depth is limited to 1 M points when
both channels are activated or 2M points when
only a single channel is activated. The signal must
be triggered /stopped to have access to the full
memory depth. Therefore when a signal is saved
the waveform will be automatically stopped if it is
not manually triggered /stopped first.
There are a number of conditions when all of the
available memory is not utilized due to a limited
number of different sample rates. This can be
caused by an un-triggered signal, or a time/div
setting that is too fast to display all the points on
screen.
Note: 2M point memory lengths are only available
for time bases slower than 10ns/div on a single
channel, and 1 M point memory lengths are only
available for time bases slower than 25ns/div on
two channels.
Waveform file
contents: other
data
A waveform file also includes the following
information.
 Memory Length
 Source
 Vertical Units
 Vertical Position
 Horizontal Scale
 Horizontal Mode
 Firmware
 Mode
 Trigger Level
 Probe
 Vertical Scale
 Horizontal Units
 Horizontal Position
 Sampling Period
 Time
 Waveform Data
GDS-1000A Series User Manual
90
Setup file format
Format
xxxx.set (proprietary format)
A setup file saves or recalls the following settings.
Contents
Acquire
 mode
Cursor
 source channel
 cursor location
 cursor on/off
Display
 dots/vectors
 grid type
 accumulation
on/off
Measure
 item
Utility
 hardcopy type
 language
 ink saver on/off
Horizontal
 display mode
 position
 scale
Trigger
 trigger type
 trigger mode
 video polarity
 pulse timing
 source channel
 video standard
 video line
 slope/coupling
Channel
(vertical)
 vertical scale
 coupling mode
 bandwidth limit
on/off
 vertical position
 invert on/off
 probe
Math
 operation type
 vertical position
 FFT window
 source channel
 unit/div
