GPP-3060/6030 User Manual
48
Operation
1. Press F4 or F5 button for operating the
corresponding Series to enter the tracking series
function. Yellow SER will be shown on the status area.
2. Press CH1 button to proceed to CH1/CH2 voltage
setting and CH1 limit current setting.
3. Press CH2 button to proceed to CH2 limit current
setting.
4. For setting operation of parameter, refer to page
38.
Output
The button ON/OFF of CH1/CH2 is
individually available, while All ON/OFF
button is available for all channels.
CAUTION: under Tracking series mode, CH1 is master,
CH2 is slave. Thus, output voltage setting is not available for
CH2.
CH1/CH2 Tracking Parallel Mode
Front panel
connection
Load
+ -
