BASIC OPERATION
49
Rear panel
with sense
connection
Output
raing
0-30V/0 -12A(GPP-3060)
0 -60V/0 -6A (GPP-6030)
Operation
1. Press F4 or F5 button for operating the
corresponding Parallel to enter the tracking
parallel function. Yellow PAR will be shown
on the status area.
2. Press CH1 button to proceed to CH1/CH2
voltage/current setting.
4. For setting operation of parameter, refer to
page 38.
Output
The button ON/OFF of CH1/CH2 is
individually available, while All ON/OFF
button is available for all channels.
CAUTION: under tracking parallel mode, CH1 is master, whilst
CH2 is slave. Thus, output voltage/current setting is not available
for CH2.
Load
