H3C S1526 Smart Ethernet Switch Chapter 4
Typical Configuration
4-5
Figure 4-4 Modify a VLAN
4) Modify the port PVID. Click the [PVID Configuration]
tab and click the port ID to enter the port PVID setting
page. All port PVIDs are 1 by default. Change the port
PVID to 200 for ports 1 through 4 one by one, as
shown in
Figure 4-5. Click <OK> to validate the
settings, as shown in
Figure 4-6.
Figure 4-5 Port PVID setting
