Hanna Instruments PCA310 User Manual

MANUAL 16:35
1.35 mg/L 2mV
6.98 pH
pH Out of Range >
3
2
4
1
CFM
MENU
SET
ESC
PCA-330
ALARM
Chlorine/pH/ORP
Analyzer
DOSING
CHLORINE
DOSING
ACID/ALK.
SYSTEM
ERROR
DISPLAY
KEYPAD
LEDS
DISPLAY, LEDS AND KEYPAD
DISPLAY
The display contains 4 lines with 20 characters on one line. The information and error messages are
clearly displayed in plain language, without error codes.
The display has back light for better visibility.
The analyzer is in main panels mode when displays a panel that contains the measured values.
Several main panels could be selected by pressing the up and down arrow keys. The PCA310 do not
have the main mode for the display.
1 - measured values
2 - controller status
3 - current time and date
4 - message line
The display is in chlorine, pH, ORP or temperature measuring panels mode when displays one of those
values and secondary information related to it. Several panels with different secondary information
could be selected by pressing the up or down arrow keys.
When the display is in one of the above modes, the measuring units, the current time and the alarm
or error status are also displayed. PCA310 is always in chlorine measuring panels.
12
