Hawk Sultan - Dimensions and Tables; Integral and Remote Unit Dimensions; Cone; Transducer Dimensions

Dimensions
Sultan Acoustic Wave Series
18
3 x M16
Conduit
entries
A
C
B
160mm (6.3”)
See
Flange
Table
53.5mm
(2.1")
305mm (12”)
80mm
(3.1”)
75mm
(2.9”)
2" BSP or
NPT THD
110mm (4.3”)
1" BSP/NPT
Nipple
B
See
Flange
Table
A
D
80mm
(3.1”)
~80mm (3.1”)
53.5mm
(2.1")
Standard Type Compact Type
(2”BSP / NPT)
Standard Type
Integral Units Remote Transducers
Compact Type
(2”BSP / NPT)
All cones must protrude
into the main volume of
the vessel by at least 50
mm (2 inches) past the
lower end of the mounting
nozzle.
Cone / Transducer Dimensions Table
Sensor
Frequency
Selected
Flange
A B C D
mm in. mm in. mm in. mm in.
5 kHz 10” 236 10.0 455 17.9 8 40 33.1 750 29.5
10 kHz
10” 236 10.0 45 5 17.9 540 21.3 45 0 17.7
8” 195 8.0 28 0 11.1 540 21.3 4 50 17.7
15 kHz
10” 236 10.0 45 5 17.9 440 17.3 350 13.8
8” 195 8.0 280 11.0 440 17.3 350 13.8
20 / 30 kHz 4” 98.5 4.0 280 11.0 390 15.4 30 0 11. 8
30 / 40 / 50 kHz 4” 98.5 4.0 280 11.0 350 3.8 260 10.2
