Specications
Sultan Acoustic Wave Series
55
Frequencies
• 4kHz, 5kHz, 9kHz, 10kHz, 15kHz, 20kHz, 30kHz,
40kHz, 50kHz
Operating Voltage
• 12-30VDC (residual ripple no greater than 100mV)
• 90-265VAC 50/60Hz
• 36-60VDC
Power Consumption
• <10VA @ 240VAC
• <3W @ 24VDC
• <6W @ 48VDC
Analog Output
• 4-20mA (750 ohms @ 24Vdc User supply, 250 ohms
internally driven)
Communications
• GosHawk, HART, Modbus, Modbus over Ethernet
TCP/IP, Profibus DP, DeviceNet,
Foundation Fieldbus, Profibus PA. Multidrop mode
can address 1-250 units over 4 wire
Relay Output
(2) Integral (5) Remote
• Form ‘C’ (SPDT) contacts, rated 0.5A at 240VAC
non-inductive.
• All relays have independently adjustable dead
bands.
• Remote fail-safe test facility for one relay.
Blanking Distance
See ‘Minimum Measurement Range’ section
Maximum Range
• 5m (16ft) 50kHz liquids
• 7m (22ft) 40kHz liquids
• 10m (33ft) 30kHz liquids, 5m (16ft) solids
• 20m (65ft) 20kHz liquids/slurries, 10m (33ft) solids
• 30m (98ft) 15kHz liquids/slurries, 20m (65ft) solids
• 60m (196ft) 10kHz liquids/slurries 40m (165ft) /
powders/solids
• 60m (196ft) 5kHz liquids/slurries/powders/solids
• 180m (588ft) 4/9 kHz for extended range position
applications
Resolution
• 1 mm (0.04”) 50, 40, 30,20, 15, 10, 5kHz
• 4 mm (0.2”) 9, 4kHz
Sensor Accuracy
• +/- 0.25% of measured range
Operating Temperature
• Integral System -40°C (-40°F) to 80°C (176°F)
• Remote electronics -40°C (-40°F) to 80°C (176°F)
• Remote transducer -40°C (-40°F) to 80°C (176°F)
Transducer / Amplier Separation
• Up to 1000m using specified extension cable
Cable
• 4 conductor shielded twisted pair instrument cable.
• Conductor size dependent on cable length.
• BELDEN 3084A, DEKORON or equivalent.
• Max: BELDEN 3084A = 500m (1640 ft)
• Max: DEKORON IED183AA002 = 350m (980 ft)
Maximum Operating Pressure
• +/- 7.5 PSI (+/- 0.5 Bar)
