Quickset Parameters
Sultan Acoustic Wave Series
24
To access to the Quickset parameter menu, press
and hold the
button until “Unlock 0” is displayed
on the LCD. Then use the
buttons to select
the access code.
The factory default is 0.
Unit
Allows the user to select the units for display of
measured distances and relay set point programming.
The choices are
metres / centimetres or feet / inches.
Low Level
Sets the distance from the face of the transducer
that corresponds to the low level in the vessel being
monitored (4mA analog output level).
High level
Sets the distance from the face of the transducer
that corresponds to the High level in the vessel being
monitored (20mA analog output level).
Note: There must be a minimum span of 100mm
between high & low levels.
Fail-Safe
Allows the user to select their preferred fail safe
condition the 4-20mA output will transmit when the
unit enters fail safe mode. There are 5 possible mA
output failure values. They are: 20mA, 4mA, Last
Known, <4.00mA and >20.00mA.
Application Type
Allows the user to select the type & speed of the
customer application to automatically program unit
settings. See dedicated ‘Application type’ on next
page.
Display Mode
Allows the user to select the primary display mode
reading. Options are average material, diff o/p, space,
material, material%, flow, volume and flow tbl. ‘Space’
is default.
Lock Code
Allows the user to set an access code other than 0 to
avoid unauthorised changes to the programming. Use
the
buttons to select the desired access code.
Quickset
