Part Numbering
Sultan Acoustic Wave Series
52
Model
AWI2 Integral 2 Wire, No relays, 12-30VDC only, Modbus
AWI234 Integral 2 / 3 / 4 Wire, 2 relays, Modbus
Housing
S Valox 357U
Power Supply
B 12-30VDC
U
1
12-30VDC and 90 -260VAC
Transducer Frequency
50 50kHz for
liquid applications up to 5m (Cone required
6
)
40 40kHz for liquid applications up to 7m (Cone required
6
)
30 30kHz for liquid applications up to 11m (Cone required
6
)
Process Temperature - Facing material selection
T Tefzel 80°C (176°F)
Transducer Housing Material
6 Tefzel
Thread Standards
TB BSP
TN NPT
Mounting Thread Sizes
20 2” thread
Additional Communication
S
1
No additional communications (5 Relays, Modbus)
X 4-20mA analogue
H
2
4-20mA analogue with HART 2 wire
`I
1
4-20mA analogue with HART Isolated 4 wire
A Profibus PA
F Foundation Fieldbus
Approval Standard
X Not Required
i0
3
IECEx Zone 0 Ex ia IIA T4 IP67 Tamb -20°C to 70°C
A0
3
ATEX Grp II Cat 1 GD IP67 EEx ia IIA T4
i20
3
IECEx Zone 20 DIP A20 TA85C IP68 Tamb -20°C to 75°C
A20
3
ATEX Grp II Cat 1 D T85°C IP67 Tamb -20°C to 75°C
A22 ATEX Grp II Cat 3 GD T85°C IP67 Tamb -40°C to 70°C
Software Options
X Not Required
AWI234 S U 40 T 6 TB 20 X X X
Sultan Integral 2”
1
Model AWI234 only
2
Model AWI2 only
3
Model AWI2 only. Communication Option W, X, H only
6
See Transducer / Cone / Flange combination table
