Hawk Sultan - Flange and Cone Selection

Part Numbering
Sultan Acoustic Wave Series
53
Flange Selection
F Flange
Dimension Standard
A ANSI
2
D DN
2
J JIS
2
Flange Sizes
2N Matches 2” NPT threaded units
2B Matches 2” BSP threaded units
3 3” acoustically isolated flange
4 4” acoustically isolated flange
6 6” acoustically isolated flange
8 8” acoustically isolated flange
10 10” acoustically isolated flange
Flange Mounting Position
1
A Cone Mounted (standard)
C Angled flange piece only
Flange Material
4 Polypropylene
F A 4 A - 4
Cone Selection
C Focaliser Cone
Cone Type
1
02N C04 cone for 2” NPT transducer
02B C04 cone for 2” BSP transducer
04 4” cone for 20kHz and
3” 30kHz transducers
08-15 8” cone for 15kHz
08-10 8” cone for 10kHz
10-15 10” cone for 15kHz
10-10 10” cone for 10kHz and 9Hz
10-05 10” cone for 5kHz and 4kHz
Cone Material
4 Polypropylene
7A Carbon Fibre. Includes matching
ANSI Flange (4”, 8” or 10”)
7D Carbon Fibre. Includes matching
DN Flange (4”, 8” or 10”)
7J Carbon Fibre. Includes matching
JIS Flange (4”, 8” or 10”)
8 Polyurethane
C 04 - 4
Additional Cone Options
1
C04-4-ZOD90 C04-4 trimmed to fit 90mm ID nozzle.
C03-4-Z Cone and coupling to fit 72mm ID
nozzle for 20kHz and 30kHz (T4).
Additional Flange Options
1
FA8A-4-C4 8” ANSI, polypropylene
FA10A- 4 - C4 10” ANSI, polypropylene
FA6D50- 4 6” ANSI, polypropylene
FA8D50- 4 6” ANSI, polypropylene
FA10D50- 4 6” ANSI, polypropylene
1
Important: See Transducer / Cone / Flange combination table for valid part combinations
2
See ‘Flange Dimension Standards’ table for full Flange specification
