Hawk Sultan - Approvals and Certifications; Safety Approvals and Standards

56
Specications / Approvals & Certication
Sultan Acoustic Wave Series
All company or product names are registered trademarks or trademarks of their respective owners.
Hawk Measurement Systems
(Head Ofce)
15 - 17 Maurice Court
Nunawading VIC 3131, AUSTRALIA
Phone: +61 3 9873 4750
Fax: +61 3 9873 4538
info@hawk.com.au
Hawk Measurement
90 Glenn Street
Suite 100B, Lawrence, MA 01843, USA
Phone: +1 888 HAWKLEVEL (1-888-429-5538)
Phone: +1 978 304 3000
Fax: +1 978 304 1462
info@hawkmeasure.com
DOC-SULTAN-MAN v1.13 0418
Beam Angle
• 7.5° without focaliser 50kHz/40kHz / 30kHz
• 4° with focaliser 50kHz/40kHz
• 6° with focaliser 30kHz/20kHz / 15kHz/10kHz/5kHz
• 10° with focaliser 9kHz/4kHz
Display
• 2 line x 12 digit alphanumeric LCD
Memory
• Non-Volatile (No backup battery required)
• >10 years data retention
Enclosure Sealing
• Integral System IP67
• Remote Electronics IP65 (NEMA 4x)
• Remote Transducer IP68
Cable Entries
• Integral: 3 x M16 Glands
• Remote: 3 x 20mm, 1 x 16mm knock outs.
Mounting
• ANSI, JIS or DIN Flange
• 4 in/100mm to 10 in/250mm
• 2in BSP Thread / NPT Thread
Typical Weight kg lb
• Remote Amplifier with 6m cable 1 2.2
• Remote Amplifier with 15m cable 3 6.6
• Remote Amplifier with 30m cable 6 13.2
• Remote Amplifier with 50m cable 10 22.0
Typical Weight
Sultan Integral / Transducer with appropriate flange
and cone
• 4/5kHz Transducer 13kg 28.6lb
• 9/10kHz Transducer 10kg 22lb
• 15kHz Transducer 8kg 17.6lb
• 20/30kHz (3”) Transducer 3kg 6.6lb
• 2” 30/40/50kHz Transducer 1kg 2.2lb
• IECEx Zone 0 Ex ia IIA T4 IP67 Tamb -20°C to 70°C
• ATEX Grp II Cat 1 GD IP67 EEx ia IIA T4
• IECEx Zone 1 Ex mb II IP68 T5(Tamb -20°C to 65°C)
T6(Tamb -20°C to 50°C)
• ATEX Grp II Cat 2 GD EEx m II IP68 T5(Tamb -20°C to 65°C)
T6(Tamb -20°C to 50°C)
• IECEx Zone 20 DIP A20 TA85C IP68 Tamb -20°C to 75°C
• ATEX Grp II Cat 1 D T85°C IP67 Tamb -20°C to 75°C
• ATEX Grp II Cat 3 GD T85°C IP67 Tamb -40°C to 70°C
• CSA Equip Class 2; Pollution deg 2; Tamb -20°C to 75°C
(Ordinary Locations)
• CSA Class I; Div 1/2; Group D; Zone 0; AEx/Ex ia IIA; T4
• CSA Class II; Div 2; Group F&G; Class III;
T6 T85 for Tamb -20°C to 75°C
• CSA Class II; Div 1; Group E, F&G; Ex mb II; T5(T100) for
Tamb -20°C to 65°C; T6(T85) for Tamb -20°C to 50°C
For queries about certification please contact
techsupport@hawk.com.au
See www.hawkmeasure.com for full safety instructions
and installation requirements in hazardous environments.
Approvals & Certication
