HBM CANHEAD - Base module CB1010

Configuration
CANHEAD A01185_11_X00_00 HBM: public 25
1)
when the internal shunt is selected,
no additional external shunt should
be plugged in
2) not included among the items sup
plied
external shunt
2)
Jumper for
internal shunt
Active jumpered
internal shunt
1)
Fig. 6.4 Shunt resistor in base module
