HBM CANHEAD - Base module (CB1014;CB1015)

Configuration
20 A01185_11_X00_00 HBM: public CANHEAD
6.1 Base module (CB1014/CB1015)
Shielding plate
Pin assignment
Base modul
2 Sgs per terminal block
Amplifier module
Additional channel for
temperature compensation
Fig. 6.2 Base module (CB1014) with amplifier module (CA1030)
The number and arrangement of the connection terminals gives the base mod
ules CB1014 (three‐wire circuit) and CB1015 (four‐wire circuit) a different
appearance (see Chapter 7).for 10 strain gage channels in a quarter bridge
circuit
The pin assignment (three‐wire or four‐wire circuit) is depicted in the lid of the
base module (see Fig. 6.2 and Section 7.1.1).
