Connecting to MGCplus
46 A01185_11_X00_00 HBM: public CANHEAD
8 Connecting to MGCplus
MGCplus AP74
1)
CANHEAD (from the back)
Termination resistor or
more CANHEAD
The documentation for the CANHEAD system with ML74B/AP74 is located on
the MGCplus system CD.
1)
The AP74 connection board in the MGCplus comes with an integrated termination resistor
