HBM CANHEAD - Meaning of the LEDs

Connection
CANHEAD A01185_11_X00_00 HBM: public 45
Hexa‐
deci
mal
Error num
ber (decimal
value)
Error Remedy
80 128 Measuring point error Check the measur
ing point
100 256 Synchronization error: gate array error Repair situation
1)
200 512 Synchronization error: bridge excitation
voltage
Repair situation
1)
1)
when the error keeps occurring
Examples:
LED flashes 7 times: errors 1+2+4:
internal bus error, hardware test failure and
wrong variables entered
LED flashes 20 times: errors 16+4:
wrong parameters (setup data) entered
