Connection
34 A01185_11_X00_00 HBM: public CANHEAD
Terminal block
Soldering terminals
Connecting cable with screen:
Always connect the braided screen directly via the appropriate terminal (see
Page 38).
Bare the wires as short as possible.
Connect the cable to the terminal block:
S Cross‐slit the cable support sleeves on the back 1 and push the cable
through from the opposite side 2
