HBM CANHEAD - Connecting CB1014 (three-wire version)

Connection
36 A01185_11_X00_00 HBM: public CANHEAD
11
1
2
3
4
5
6
7
8
9
10
Channel
2 SGs per terminal block
Additional channel
for temperature com
pensation
Fig. 7.1 Connecting CB1014 (three‐wire version)
