Busaufbau
18 A01185_11_X00_00 HBM: public CANHEAD
TR
TR
Power
Supply
TR
trunk line
drop lines
device or node
terminating resistor
Abb. 5.3 Linienbus und Stichleitungen (Beispiel aus dem Devicenet Handbuch)
