Internal calculation channels
PMX A4354-2.2 HBM: public 201
Parameters Interval [s]:
Maximum 100,000 s.
Single Shot (On/Off)
Pulse Length [s]:
Defines the hightime of the Elapse Flag. Maximum 100,000
s. When equal to zero, the Elapse Flag gets high for one
calculation cycle.
Default Run input: Constant high
Interval: 1 s
Single Shot: Off
Pulse Length: 0.1 s
Exception handling None. The output is always valid.
13.2.2.10Trigger function (pulse)
Function Provide a digital trigger signal dependent on an input value.
The trigger gets high (low with isHighActive = false) when
threshold_low <= input <= threshold_high
The trigger gets low (high) when
input < (threshold_low
– hysteresis)
OR
input > (threshold_high + hysteresis)
threshold_high threshold_low
