Startup
142 A4354-2.2 HBM: public PMX
11.4 Display and control options
Important
For a detailed description of PMX operation see the PMX
online help. To download the current firmware go to
http://www.hbm.com/en/menu/support/software-firmware-
downloads/industrial-amplifiers/
The overview shows the modules (amplifiers) present in
the device, with current measured values, the status of
the digital inputs/outputs and the bus systems (if
present), as well as the calculated channels.
Touch or click on one of the targets, or one of the places
where the cursor turns into a hand, to change the
relevant setting or to get to the dialog to change the
setting.
Calls the setting menu, from which you can reach all the
dialogs by using the tabular menu structure. There are
additional submenus in all the menu items for which a
triangle shows in the bottom-right corner. As soon as you
have selected a menu item, the menu path is displayed
next to the symbol for the setting menu.
Important
If you change a setting, is displayed at the bottom right,
as the setting is initially only stored in the RAM. Touch or
click on this symbol, to save the setting, power failsafe in
the flash EPROM.
