Electrical connections PMX

PMX A4354-2.2 HBM: public 79

8.4.3.1 Voltage source ± 10 V

+ U

Cable shield

TEDS

OUT +

OUT -

Excitation for

external

transducers

TEDS

module

(optional)

Fig. 8.6 PX401 plug terminal Voltage source ±10 V
