HBM PX455 - Current Source ± 20 Ma

To Next Page

To Previous Page

Electrical connections PMX

80 A4354-2.2 HBM: public PMX

8.4.3.2 Current source ± 20 mA

+ I

TEDS

module

(optional)

OUT +

OUT -

Excitation for

external

transducers

Cable shield

Fig. 8.7 PX401 plug terminal Current source ±20 mA (4-wire

circuit)
