Electrical connections PMX
PMX A4354-2.2 HBM: public 71
8.4.2 PX455
Four individually configurable 4 SG full or half
bridges (4.8kHz CF). Inductive full or half bridges,
LVDT, potentiometric sensors, piezoresistive
sensors, TEDS (0-wire), sensor detection
0‐wire TEDS
see Chapter 8.7.3
The bridge excitation voltage is 2.5 V.
