Electrical connections PMX

PMX A4354-2.2 HBM: public 91

8.4.4.3 Frequency measurement symmetrical

(differential)

Transducer 1

Transducer 2

Transducer excitation not shown

Twisted pair

GND

Shunt optional

TEDS

module

(optional)

Fig. 8.14 PX460 pin assignment two frequencies, differential

Possible channel setting via web server:

Transducer 1 : Frequency (digital), permanent

Transducer 2 : Frequency (digital), counter, PWM
