Electrical connections PMX

PMX A4354-2.2 HBM: public 65

8.2.5 Measurement card LEDs

PX401, channel status

Status LED

LED Status Significance

green

On no errors

yellow

Flashing Firmware update

red

Parameter not OK,

overloaded
