HBM PX455 - Strain Gage and Inductive Full and Half Bridges; (4-Wire Configuration)

Electrical connections PMX
PMX A4354-2.2 HBM: public 73
8.4.2.2 Strain gage and inductive full and half
bridges (4-wire configuration)
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
1
2
3
4
3'
2'
wh
bk
rd
bu
ye
Feedback bridges for a four-wire configuration
Four-wire connection:
full bridge
1
2
3
3'
2'
gn
ye
Connection: Half bridge
gy
wh
bk
bu
Fig. 8.2 PX455 plug terminal in four/three-wire configuration
