PMX command set (API)
482 A4354-2.2 HBM: public PMX
21.3 Examples
Simple case of measurement values configuration
Terminology:
PMX command list example in a Telnet session under
Microsoft Windows
PMX Names Catman Interface Names
Equipped card slots channels
Physical channels on a
card
subchannels
Types of internal
channels:
Original, Min, Max, PP
Signals:
Gross, Min, Max, Max-Min
Example:
Select a filter globally and record subchannels that have
been put into measurement rate groups.
Please do not change this example in this document,
because an example code refers to it!
pcs 0 (x) sps 0 (x) sfc 141,969 (x)
pcs 1 (x) sps 3,4 (x) mrg 0 (x)
pcs 2 (x) sps 1,2 (x) mrg 1 (x)
icr 6320,0 (x)
icr 6319,1 (x)
pcs 1 (x) sms 3,4 (x) sps 3,4 (x) mss 214 (x)
pcs 2 (x) sms 1,2 (x) sps 1,2 (x) mss 214 (x)
mcs 1,2 (x)
tsv 10 (x)
omp? 0 (x) omp? 1 (x)
rmb? 10,6409,0 (x) rmb? 10,6409,1 (x)
