Model overview, scope of supply, accessories
34 A4354-2.2 HBM: public PMX
5.2 Scope of delivery
Order No.
1 PMX basic device, with a wall mounting kit (1 wall bracket, 4
screws, 4 washers) and a set for DIN rail mounting
with CAN connection and CODESYS‐V3 Soft‐PLC
without CAN connection, without CODESYS
1-WGX001
1-WGX002
For each measurement card : A mating connector for each
channel, all mating connectors with Push-In technology
(4 connectors are enclosed for each measurement card,
complete with coding pins)
1-CON-S1008
1-CON-S1012 for
PX460
DIN rail mounting
(2 units, packed in film cushion packaging with the mounting
material in an Etimex bag)
(4 M5x10 close tolerance screws, 4 spring washers)
1-RAILCLIP
PMX system CD with operating manual and data sheet, safety
instructions and quick start guide
For WGX001: Delivery with CODESYS‐CD (CODESYS‐V3
software, PMX package quick start guide and program
examples)
Mating connector M12x1 for CAN interface for WGX001 1-CON-S1002
Mating connector for PMX voltage supply (WGX001 / WGX002) 1-CON-S1010
5.3 Accessories
Accessories Order No.
Ethernet crossover cable, for direction operation of devices on a
PC or notebook, length 2 m, type CAT5+
1-KAB239-2
AC/DC power supply unit;
Input: 90 V … 264 VAC, 1.5 m cable, output: 24 V DC, max.
1.25 A, 2 m cable with ODU plug
1-NTX001
