Internal calculation channels
222 A4354-2.2 HBM: public PMX
13.2.4.10Timer
Function Either single shot or continuously running timer. When
elapsed, a flag is set to high level.
Maximum interval 100,000 s. Resolution = 1/Calculation Rate,
see above.
Inputs Run (digital):
In single shot mode, a low to high transition starts the timer. A
high to low transition does not stop the timer.
In continuous mode, a high level starts the timer. A low level
stops the timer immediately.
Outputs Elapse flag: Is set to high when the timer elapses
In single shot mode, the flag gets high for one calculation
cycle when the parameter Pulse Length equals 0. Otherwise
the flag gets high until the next timer start.
In continuous mode, the flag gets high for the time defined
with parameter Pulse Length.
Time [s]: The current timer value.
While the timer is stopped, Interval is output.
