Electrical connections PMX

PMX A4354-2.2 HBM: public 77

Cable shield

Measurement

signal +

Sense lead -

Sense lead +

Bridge excitation

voltage +

Bridge excitation

voltage -

PX455

Resistance thermometer

Fig. 8.5 PX455 with PT100 element for temperature

measurement
