Electrical connections PMX

PMX A4354-2.2 HBM: public 97

Potential isolation

PX460 housing

Shunt

Pin 7 not connected or connected as output:

If Pin 7 is connected as

input, both potential

ranges are connected

(see Chap. 8.4.4.8)

Fig. 8.20 Potential isolation PX460
