HBM T10FS User Manual

Loading capacity
76 A0785-150 HBM: public T10FS
loading bandwidth specified by -M
nom
and +M
nom
(at 100 N@m: -2 M
nom
and +2 M
nom
1)
. The same also
applies to transient resonance points.
+M
nom
100 %
-M
nom
100 %
0
Nominal (rated) torque M
nom
as a %
Vibration bandwidth 200 % M
nom
(Measuring range 100 N@m:
400 % and 3...10 kN⋅m: 160 %)
Oscillation width
Fig. 9.1 Permissible dynamic loading
1)
Metrologically, however, the transducers can only be used up to the control range.
