HBM T10FS User Manual

Dimensions
86 A0785-150 HBM: public T10FS
Measuring
range
Dimensions (in mm; 1 mm = 0.03937 inches)
b ∅d ∅D H1 H2 H3 h l
ROT
h
ROT
1)
100 N⋅m
17.5 125 155 235 239 253 157.5 38 100
200 N⋅m
500 N⋅m
17.5 145 175 255 259 273 167.5 36 100
1 kN⋅m
2 kN⋅m
20.5 181 211 291 295 309 185.5 37 100
3 kN⋅m
5 kN⋅m 22.5 215 245 325 329 343 202.5 51 105.5
10 kN⋅m 28.5 263 293 373 377 391 226.5 52 105.5
1)
Variable by ±1.5 mm at the head of the sensor
