HCFA Q Series User Manual

1
Introduction
Thank you for purchasing Q series PLCs and the extension modules.
This manual gives the necessary information for the use of HCFA Q series PLCs and extension modules,
please read this manual carefully before use and make the correct operation with full attention to safety.
Store this manual in a safe place so that it can be taken out and read whenever necessary.
Applicable readers
For the users of HCFA Q series PLC, refer to this manual to perform the wiring, installation, diagnosis and
maintenance and requires the users to have the certain knowledge of electrical and automation.
Main contents
Safety precautions：The following notation is used in this user’s manual to provide precautions required
to ensure safe usage of Q series PLCs.
Version description： Check the version of PLCs on the nameplate
Chapter 1 mainly introduces Q series PLCs system configuration and startup process.
Chapter 2 mainly introduces model name of Q series PLCs and the extension modules.
Chapeter 3 mainly introduces the specifications of Q series PLCs and the extension modules.
Chapter 4 mainly introduces the assembly, wiring and installation for Q series PLCs and the extension
modules.
Chapter 5 mainly introduces the operation, maintenance and diagnosis of Q series PLCs.
The appendix mainly introduces the specificaions for customized cables and screwdriver.

HCFA Q Series Specifications

General

Brand	HCFA
Model	Q Series
Category	Controller
Language	English
