HCFA Q Series User Manual

48
3-2-7 Analog (voltage) input module specifications
This module is a 16-bit analog input module based on the EtherCAT, which can perform peak value
monitoring, limit value monitoring, disconnection detection, user scale adjustment, auto tuning and input
filtering setting.
Items
Technical specifications
Input channel
4(differential)
Signal voltage
0~10V、-10~10V、-5~5V、0~5V、1~5V
Voltage input resistance
> 200 kΩ
Signal current
0~20mA、4~20mA
Current input resistance
250Ω
Input filter limit frequency
5Khz（second-order filter）
Common-mode voltage U
CM
Up to 35 V
Resolution
24 bit
Channel data refresh time
About four channels take 1ms
Measurement error（Total error
range ）
< ± 0,3 % (full scale)0.8%(current)
QBUS power consumption
1W（Typ）
Electrical isolation
500 V
eff
(Backboard/Input interface)
Setting
No need to set the address, can be configured through CODESYS
Weight
About 90g
Working temperature
0 °C ... + 55 °C
Storage temperature
-25 °C ... + 85 °C
Analog input module basic specifications
Figure 0-5 Digital I/O module dimensions
