HCFA Q Series User Manual

42
3-2 Performance specifications
This section will mainly describe the specifications and dimension for CPU unit and extension
modules.
3-2-1 CPU unit specifications
Items
Technical specifications
Programming method
IEC61131-3 programming language（IL、LD、FBD、ST、CFC、SFC）
Program execution method
Compile execution
I/O control method
Bus refresh mode
Max. number of I/O units
10（Refer to the max. I/O points when connecting extension modules）
Max. number of I/O points
65535points（excluding special function modules）
Dimension（L*W*H）
About 132mm*100mm*100mm
Program storage space
100MB , can be extended
Flash hold space after power-failure
1MB
RAM
1GB
ROM
4GB
Program hold method after power-failure
Flash hold
Interruption mode
16 points input interruption （ CPU built-in high-speed DI ）， supporting
risingedge and failing edge interruption
CPU unit high-speed I/O
Input：16 points Output16 points
Self-diagnosis function
CPU error，data frame transmission error, etc.
 High-speed input specifications
Items
Technical specification
Signal name
High-speed input（DI0-DI15）
Rated input voltage
DC24（+20%~-15%， pulse ripple within 10%）
Rated input current
3.65mA
ON-current
>4.14mA
OFF-current
<3.88mA
Input impedence
1.5K
Max. counting speed
100KHZ（Version 2.XX.XX）200KHz（Version 3.XX.XX or more）
2-phase input worst duty ratio
（40%：60%）~（60%：40%）
Common method
Evey 8 points share a common terminal.
 High-speed output specifications
Items
Technical specification
Signal name
Output（DO0-DO15）
Output polarity
Sink output（NPN）
CPU unit performance specifications
CPU unit high-speed I/O specifications
