HEIDENHAIN iTNC 530 185

5.3 Tool Compensation

Entering radius compensation

Radius compensation is entered in a G01 block:

To select tool movement to the left of the

programmed contour, select function G41, or

To select tool movement to the right of the contour,

select function G42, or

To select tool movement without radius

compensation or to cancel radius compensation,

select function G40

To terminate the block, press the END key.
