Coordinate transformation
Q-parameter definitions
Coordinate
transformation
Activate Cancelation
Datum
shift
G54 X+20 Y+30
Z+10
G54 X0 Y0 Z0
Mirror image G28 X G28
Rotation G73 H+45 G73 H+0
Scaling factor G72 F 0.8 G72 F1
Working plane G80 A+10 B+10
C+15
G80
Working plane PLANE ... PLANE RESET
D Function
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
19
Assignment
Addition
Subtraction
Multiplication
Division
Root
Sine
Cosine
Root sum of squares c = √ a
2
+b
2
If equal, go to label number
If not equal, go to label number
If greater than, go to label number
If less than, go to label number
Angle from c sin a and c cos a
Error number
Print
Assignment PLC
