264 Programming: Q Parameters
9.5 If-Then Decisions with Q Parameters
Programming If-Then decisions
Press the JUMP soft key to call the If-Then conditions. The TNC then
displays the following soft keys:
There are 3 possibilities to enter the jump address:
Label number, selectable via LBL NUMBER soft key
Label number, selectable via LBL NAME soft key
String number, selectable via QS soft key
Function Soft key
D09: IF EQUAL, JUMP
Example: D09 P01 +Q1 P02 +Q3 P03 “SPCAN25” *
If the two values or parameters are equal, jump to the
given label.
D10: IF UNEQUAL, JUMP
Example: D10 P01 +10 P02 -Q5 P03 10 *
If the two values or parameters are unequal, jump to
the given label.
D11: IF GREATER, JUMP
Example: D11 P01 +Q1 P02 +10 P03 QS5 *
If the first value or parameter is greater than the
second, jump to the given label.
D12: IF LESS, JUMP
Example: D12 P01 +Q5 P02 +0 P03 “ANYNAME” *
If the first value or parameter is less than the second,
jump to the given label.
