HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual

278 Programming: Q Parameters
9.9 String Parameters
Assigning string parameters
You have to assign a string variable before you use it. Use the DECLARE
STRING command to do so.
U Show the soft-key row with special functions
U Select the menu for defining various plain-language
functions
U Select string functions
U Select the DECLARE STRING function
Example NC block:
N37 DECLARE STRING QS10 = “WORKPIECE”
