HEIDENHAIN iTNC 530 565
17.16 Displaying Operating Times
17.16 Displaying Operating Times
Application
The MACHINE TIME soft key enables you to see various types of
operating times:
Operating time Meaning
Control on Operating time of the control since being
put into service
Machine on Operating time of the machine tool since
being put into service
Program run Duration of controlled operation since being
put into service
The machine tool builder can provide further operating
time displays. Refer to your machine tool manual.
At the bottom of the screen you can enter a code number
to have the TNC reset the displayed times. The machine
tool builder defines exactly which times the TNC resets,
so refer to your machine manual for more information.
